An Overview of Epithermal Gold Deposits

- November 7th, 2019

Epithermal gold deposits are often appealing to mining companies because they are typically high-grade, small-size deposits.

Epithermal deposits are a type of lode deposit. They contain economic concentrations from a precious metal such as gold and silver, and in some cases base metals such as copper, lead, iron ore and zinc

Like other lode deposits, the minerals in epithermal deposits can be disseminated throughout the orebody, though more often they are contained in a network of veins. Aside from epithermal deposits, classic examples of lode gold deposits include VMS deposits and Carlin-type deposits.

Gold is often the dominant metal in epithermal deposits, and for that reason epithermal gold deposits are a key point of interest when discussing epithermal deposits. Read on for a brief overview of epithermal gold deposits, from how they form to what the different types are. These deposits can be very desirable to mining and exploration companies, and it’s worth being aware of what makes them so alluring.

Is gold a good hedge investment?


Get an in depth market report for free!


Formation of epithermal gold deposits

Epithermal deposits are distinctive from low-grade bulk tonnage deposits such as porphyries in that they are typically high-grade, small-size deposits. A few other characteristics distinguish epithermal deposits. Perhaps most notably, they are found at shallow depths, meaning that they are susceptible to erosion and can be easily mined.

As mentioned, epithermal gold deposits are often found in an area near the Earth’s surface. In fact, mineralization generally occurs at a maximum depth of 1.5 kilometers, and rarely runs deeper than 600 meters, making these different than orogenic gold deposits and perfect for mining companies that want to get metal out of the ground easily.

Due to their shallow depth, epithermal gold deposits form under a moderate crustal temperature of less than 300 degrees Celsius and under medium pressure. These mineral deposits commonly occur in island, volcanic and continental arcs associated with subduction. However, they can also be found in shallow marine environments and in association with hot springs.

But how exactly do epithermal gold deposits form? Ground water is key to the process — when it comes into contact with hot molten rocks deep underground, the silicate minerals in the rocks are dissolved, as are metals within the sedimentary rocks, including gold, silver, lead and zinc. This ground water is also known as hydrothermal fluid, and as it moves it enters open spaces, such as cracks, joints and faults in the rock. Eventually the hydrothermal fluid cools, creating veins, and the resulting material contains the dissolved metals.

Nearly any rock type may host epithermal gold deposits. However, they are most commonly found in igneous and sedimentary rocks. Typically, epithermal gold deposits are younger than their enclosing rocks, except in cases where deposits form in active volcanic settings and hot springs.

Ready to profit from precious metals this year?


Read your free report today for stocks, market data and more...

Today most epithermal gold deposits are brought to the surface using open-cut pit technologies, though in the past underground techniques were used. As already noted, veins in these deposits tend not to extend far underground, but are often high grade. The Nevada-based Comstock deposit and Cripple Creek Colorado deposit are examples of epithermal bonanzas.

Types of epithermal gold deposits

Epithermal gold deposits can be broken down into three main subtypes. Each of these subtypes has its own characteristic alteration mineral assemblages, occurrences, textures and, in some cases, characteristic mineral assemblage suites. The subtypes are as follows:

  • High sulfidation ores
  • Intermediate sulfidation ores
  • Low sulfidation ores

As explained above, gold is often the dominant metal in epithermal deposits, but that is not always the case. Sometimes these deposits hold more silver than gold — indeed, metals ratios vary widely among deposits, and even within a given deposit. Typically, silver-to-gold ratios tend to be higher in low-sulfidation deposits than in high-sulfidation deposits.

All three deposit subtypes form under similar circumstances; however, intermediate- and high-sulfidation deposits form at greater depths. Unsurprisingly, high-sulfide deposits tend to be richer in sulfides, and may contain pyrite and enargite in addition to gold and silver. These higher-sulfide epithermal deposits tend to be linked to porphyry deposits.


INNdepth

Want more details? Check out these articles for more INNdepth coverage.

Want an overview of investing in gold stocks? Check An Overview of Gold Stocks and Price.


This is an updated version of an article originally published by the Investing News Network in 2011.

Don’t forget to follow us @INN_Resource for real-time news updates.

Securities Disclosure: I, Nicole Rashotte, hold no direct investment interest in any company mentioned in this article.

Is gold a good hedge investment?


Get an in depth market report for free!


Get the latest Gold Investing stock information

12 responses to “An Overview of Epithermal Gold Deposits

  1. In its attempts to generalize and be succinct, this article is imprecise and makes several misleading statements, such as:
    1) Epithermal deposits are primarily gold: Not true, there are numerous examples of silver-dominant epithermal deposits with minor amounts of gold relative to the silver content including Tonapah, Nevada, USA; Tayoltita, Durango, Mexico; Pachuca, Hidalgo, Mexico; Fresnillo, Durango, Mexico; Potosi, Bolivia; Los Gatos, Chihuahua, Mexico; Escobal, Guatemala; Dukat, Far East, Russia; etc. In general, I place the dividing line between gold-dominant and silver-dominant systems a a silver:gold ratio of 40. The crustal abundance Ag:Au ratio is about 50. Ag:Au ratios range from 1000.
    2) Epithermal deposits, by definition, are near surface deposits, generally forming at depths of < 1 km as stated but are not characerized by replacement but by open-space filling textures though replacement also occurs. The open-space-filling textures reflect their location in brittle rock above the ductile-brittle transition and formation at near hydrostatic pressure which presume open communication of the fluid to the paleosurface at time of formation. Consequently, the hydrothermal fluids often boil and this is one mechanism of gold-silver mineral deposition.,
    3) Temperatures of ore deposition are not as low as 50 degrees Centigrade. The top of the ore is typically characterized by temperatures of 180-200C and the bottom of the precious metal zone by temperatures of 260-300C. Some hot spring gold deposits in which deposits occur immediately below sinters, such as McLaughlin in Nevada, gold deposition may have occurred at temperatures as low as 110C.
    4) Epithermal deposits can be very large. Examples of large tonnage epithermal deposits include Round Mountain, Nevada, USA; Lahir, Papua New Guinea; Pascua-Lama, Chile; Velardena, Argentina; Cripple Creek, Colorado, USA.
    4) All hydrothermal mineral deposits are, with the rare exception of mineralized sinters, younger than the host rock, though when they occur in association with volcanic rocks, the volcanic rocks are often only slightly older.
    5) When significant gold in present in silver-rich epithermal systems. veins typically zone downward from a near surface gold-rich zone to intermdiate depth silver-rich zone then to deeper base metal zone. The Silverton District in Colorado is an excellent example of vertical zonation as is the San Sebastian mine, Durango, Mexico. Vertical zonation is not always the case. Lateral zonation also occurs as at La Cienega, Durango, Mexico.
    6) Low sulfidation deposits are not typically silver-rich relative to intermediate or high sulfidation epithermal deposits. McLaughlin, California, Knob Hill, Republic, Washinton, USA; Cripple Creek, Colorado, USA; Round Mountain, Nevada, USA; El Oro, Mexico, Mexico; Bullfrog, Nevada, USA; Kupol, Far East, Russia; and Lahir, PNG are all low sulfidation deposits with low Ag:Au ratios. At Round Mountain Ag:Au ratios in the core of the deposit are as low as 2 and on the periphery of the deposit, are as high as 20. The Gold Hill deposit, just to the north of Round Mountain 3 miles or so is unrelated to the Round Mountain deposit and is a silver-dominant system.

    1. Hi Kenneth
      Saw your expanded comments on recent article on Epithermal deposits. ANd, thank you for correcting and expanding the more current view of epithermal deposits.
      One of the Companies mentioned is Bellhaven (BHV.VE). We are in the processing of acquiring one of their concessions that appears to have many of the characteristics you mention–but, in this case it is Mn with secondary gold..
      I would love to further this discussion with you,, please replay to the email above (dr.mike.hirschberger779977@gmail.com) when u get a chance.
      Dr. Mike Hirschberger-Principal-Global Min-Metals, SA.

  2. In its attempts to generalize and be succinct, this article is imprecise and makes several misleading statements, such as:
    1) Epithermal deposits are primarily gold: Not true, there are numerous examples of silver-dominant epithermal deposits with minor amounts of gold relative to the silver content including Tonapah, Nevada, USA; Tayoltita, Durango, Mexico; Pachuca, Hidalgo, Mexico; Fresnillo, Durango, Mexico; Potosi, Bolivia; Los Gatos, Chihuahua, Mexico; Escobal, Guatemala; Dukat, Far East, Russia; etc. In general, I place the dividing line between gold-dominant and silver-dominant systems a a silver:gold ratio of 40. The crustal abundance Ag:Au ratio is about 50. Ag:Au ratios range from 1000.
    2) Epithermal deposits, by definition, are near surface deposits, generally forming at depths of < 1 km as stated but are not characerized by replacement but by open-space filling textures though replacement also occurs. The open-space-filling textures reflect their location in brittle rock above the ductile-brittle transition and formation at near hydrostatic pressure which presume open communication of the fluid to the paleosurface at time of formation. Consequently, the hydrothermal fluids often boil and this is one mechanism of gold-silver mineral deposition.,
    3) Temperatures of ore deposition are not as low as 50 degrees Centigrade. The top of the ore is typically characterized by temperatures of 180-200C and the bottom of the precious metal zone by temperatures of 260-300C. Some hot spring gold deposits in which deposits occur immediately below sinters, such as McLaughlin in Nevada, gold deposition may have occurred at temperatures as low as 110C.
    4) Epithermal deposits can be very large. Examples of large tonnage epithermal deposits include Round Mountain, Nevada, USA; Lahir, Papua New Guinea; Pascua-Lama, Chile; Velardena, Argentina; Cripple Creek, Colorado, USA.
    4) All hydrothermal mineral deposits are, with the rare exception of mineralized sinters, younger than the host rock, though when they occur in association with volcanic rocks, the volcanic rocks are often only slightly older.
    5) When significant gold in present in silver-rich epithermal systems. veins typically zone downward from a near surface gold-rich zone to intermdiate depth silver-rich zone then to deeper base metal zone. The Silverton District in Colorado is an excellent example of vertical zonation as is the San Sebastian mine, Durango, Mexico. Vertical zonation is not always the case. Lateral zonation also occurs as at La Cienega, Durango, Mexico.
    6) Low sulfidation deposits are not typically silver-rich relative to intermediate or high sulfidation epithermal deposits. McLaughlin, California, Knob Hill, Republic, Washinton, USA; Cripple Creek, Colorado, USA; Round Mountain, Nevada, USA; El Oro, Mexico, Mexico; Bullfrog, Nevada, USA; Kupol, Far East, Russia; and Lahir, PNG are all low sulfidation deposits with low Ag:Au ratios. At Round Mountain Ag:Au ratios in the core of the deposit are as low as 2 and on the periphery of the deposit, are as high as 20. The Gold Hill deposit, just to the north of Round Mountain 3 miles or so is unrelated to the Round Mountain deposit and is a silver-dominant system.

    1. Hi Kenneth
      Saw your expanded comments on recent article on Epithermal deposits. ANd, thank you for correcting and expanding the more current view of epithermal deposits.
      One of the Companies mentioned is Bellhaven (BHV.VE). We are in the processing of acquiring one of their concessions that appears to have many of the characteristics you mention–but, in this case it is Mn with secondary gold..
      I would love to further this discussion with you,, please replay to the email above (dr.mike.hirschberger779977@gmail.com) when u get a chance.
      Dr. Mike Hirschberger-Principal-Global Min-Metals, SA.

  3. I surprised that Goldfield Nevada wasn’t brought up in any conversation, that high acid deposit yielded almost 5 million ounces of gold from an area about 600′ by 1500′ !! Some ore assayed at over 2800 ounces per ton !!!!

  4. I surprised that Goldfield Nevada wasn’t brought up in any conversation, that high acid deposit yielded almost 5 million ounces of gold from an area about 600′ by 1500′ !! Some ore assayed at over 2800 ounces per ton !!!!
