Focus Graphite Inc. (TSXV:FMS) (OTCQX:FCSMF) (FSE:FKC) (“Focus” or the “Company”) is pleased to report it has developed a silicon-enhanced graphite anode for next generation lithium-ion batteries.
Testing in CR2016 coin cells showed the Company’s initial efforts to introduce nano-sized silicon into Lac Knife spherical graphite anode materials were successful in nearly doubling the capacity of Lithium-Ion batteries currently using synthetic and standard flake graphite in the anode mix.
Dr. Joseph Doninger, Focus Director of Manufacturing and Technology – who headed the testing program – said the testing results pushed performance well beyond the prescribed limits of theoretical reversible capacity of 372 Ah/kg for lithium-ion battery cells.
“Our aim has always been to create and develop scientific solutions that not only work, but solutions that win for our customers and the marketplace,” said President and Chief Executive Officer Gary Economo.
“The combination of our graphite resource at Lac Knife and the in-house scientific and technical capabilities to overcome performance and safety issues related to Lithium-Ion batteries may well represent a significant step forward for the battery industry,” Mr. Economo said.
In a February 25, 2015 news release, the Company announced its spherical graphite (SPG) exhibited superior performance in coin cells when compared with commercial grades of synthetic graphite. This data is shown in Figure 1 below:
As shown, Focus Graphite’s carbon coated fine grade of spherical graphite (SPG) at a reversible capacity of 366 Ah/kg is very close to the theoretical limit of 372 Ah/kg achievable with graphite. In addition, coin cells made with the two commercial grades of synthetic graphite achieved reversible capacities of only 345 and 347 Ah/kg, about 6% lower in capacity than the Lac Knife SPG. However, both the excellent performance of the Focus SPG and the commercial grades of synthetic graphite used in the anode have almost half of the capacity achieved with the new Focus silicon-enhanced Lac Knife SPG.
With pure silicon alone used as the anode material, theoretical reversible capacities as high as 4200 Ah/kg are possible. However, there is a serious problem with using silicon in that it swells and contracts as much as much as 400% during the lithiation and de-lithiation process that occurs during cycling. This results in the formation of an unstable anode and hence an unusable lithium-ion battery. Much work has been reported in the literature to add lithium to the graphite used in the anodes but continuing stability problems caused by the swelling of the silicon have held back its development.
“Focus Graphite has developed a process that addresses this problem and as indicated in Figure 2 below, with the addition of 18 wt. % silicon nanoparticles into our Lac Knife SPG, we have shown the possibility of achieving a reversible capacity value of 613 Ah/kg – almost twice the capacity of the commercially available grades of synthetic graphite and our standard Lac Knife spherical graphite,” said Dr. Doninger.
Figure 2. http://www.globenewswire.com/NewsRoom/AttachmentNg/eecb53bd-2725-4e04-81a7-a0a4fd975851
This data was presented at the 30th International Electric Vehicle Symposium and Exhibition held from October 9th to 11th, 2017, in Stuttgart, Germany. A copy of the paper presented is available on the Focus website via the following link: Electrochemical Performance of Lac Knife Natural Crystalline Flake Graphite from Quebec, Canada in Lithium Ion Batteries.
As shown above, a reversible capacity of 613 Ah/kg was achieved with the Lac Knife silicon-enhanced SPG at a C/20 rate after the first cycle which is the same charging rate that was used in the coin cell tests run on the synthetic and Lac Knife graphite anode materials shown in Figure 1. Although the irreversible capacity loss (ICL) after the first cycle was 26.4% compared to 0.7% for the untreated SPG, the high reversible capacity achieved with the silicon-enhanced SPG indeed is quite remarkable particularly since these tests were conducted on an uncoated grade of spherical graphite.
“Additional testing is being planned to optimize both the formulations and process used to produce the silicon-enhanced Lac Knife SPG. These tests, along with coating the SPG with carbon to cushion the swelling that can occur due to the presence of silicon in the graphite, should result in further increases in the reversible capacity and decreases in the irreversible capacity loss.
“Ultimately, we have developed a silicon-enhanced graphite based anode that results in an incredible increase in the capacity potential for lithium-ion batteries,” Dr. Doninger said.
Mr. Economo said the Company’s ongoing, long-term product testing program has contributed to the development of a complete range of technology graphite products – including new graphite products to the industry.
“The advances we have made in the development of our superfine graphite anode materials, our expanded graphite for Lithium-Ion battery cathodes and, now; silicon-enhanced spherical graphite for anodes underscores our aims and objectives of meeting industry needs,” Mr. Economo said.
“And that is, to provide manufacturers with higher-performing, lower cost graphite materials and products to meet next generational requirements,” he said.
Mr. Economo said battery manufacturers and institutions are currently testing Focus’ Lac Knife graphite products globally. The average testing period is approximately 24 months with some potential customers nearing the end of their long-term evaluations.
The following figures provide a partial overview of the scope of Focus Graphite’s silicon-doped graphite anode test project results.
Figure 3. http://www.globenewswire.com/NewsRoom/AttachmentNg/668f3aaf-526b-4703-8a17-878bcddc5ff1
Figure 4. http://www.globenewswire.com/NewsRoom/AttachmentNg/25395abf-bad9-49e4-ad74-95f4334a2bde
Dr. Joseph Doninger, Focus Graphite’s Director of Technology and Manufacturing is the Qualified Person under National Instrument 43-101 – Standards of Disclosure for Mineral Projects – has reviewed and approved the technical content of this news release. Dr. Doninger is the developer and co-developer of a number of U.S., European and Canadian patents related to carbon processing methodologies and processing equipment. Also, a chemical engineer, Dr. Doninger is the author and co-author of some two dozen technical papers and studies related to graphite composite anodes; carbon-based materials for electrochemical energy storage systems; advanced graphite for Lithium-ion batteries and other related publications.
About Focus Graphite
Focus Graphite Inc. is an advanced exploration and mining company with an objective of producing graphite concentrate at its wholly owned Lac Knife flake graphite deposit located 27 km south of Fermont, Québec. In a second stage, to meet Quebec stakeholder interests of transformation within the province and to add shareholder value. Focus is evaluating the feasibility of producing value added graphite products including battery-grade spherical graphite.
Focus Graphite is a technology-oriented graphite mining development company with a vision for building long-term, sustainable shareholder value. Focus also holds a significant equity position in graphene applications developer Grafoid Inc.
