MGX Minerals Inc. (“MGX” or the “Company”)(CSE:XMG) is pleased to report additional assay results of Petroleum Coke (“Petcoke”) samples collected from stockpiles produced from the Fort McMurray area mining and upgrading operation as well as the Edmonton refinery. Both samples originated from Delayed Coking operations. Samples were obtained and prepared by Highbury Energy Inc. (“Highbury”) and metal contents analyzed by Acme Labs of Vancouver, British Columbia using standard ICP analyses.
Ash was determined by weighing residues after burning coke samples of about 200 g in air in a muffle oven over extended periods at 815°C. Table A indicates the average ash content of 6 to 7 samples of each coke.
Table A. Ash Content of Coke Samples
|Sample name||Ash content (% wt.)||No. of samples tested|
|Upgrader Coke A||2.73 ±0.09||6|
|Refinery Coke B||0.32 ±0.04||7|
Upgrader Coke A had about nine times as much ash as was in Refinery Coke B.
The cokes contain over 95 % organic (non-mineral) matter. Thermogravimetric analyses on 10 mg quantities are shown below.
Table B. Proximate Analyses of Coke by the Thermo-gravimetric Analyser Method
|Quantity (wt. %)||Upgrader Coke A||Refinery Coke B|
Residue refers to residual mineral matter left after the thermo-gravimetric test. Except for the % Residue, the two cokes have similar combustion properties.
Metals Analysis in the Coke Samples
Lithium borate fusion ICP-MS method measures 45 trace metal concentrations in the coke. Results are expressed as (mg/kg) or ppmwt. Table C lists concentrations of selected metals.
Table C. Selected Metal Concentrations in Coke (mg Metal/kg Coke)
|Upgrader Coke A||421||76.8||86.2||40.5||4.8||0.0011||< 0.1|
|Refinery Coke B||458||53.4||35.9||1.3||1.3||<0.0005||<0.1|
Vanadium is the highest concentration of the 45 trace metals detected in the coke samples.
Ash analysis was completed by Bureau Veritas Commodities Canada Ltd. (“BV”) of Vancouver, British Columbia using XRF method (XF701). Results are expressed as % wt. in the ash as oxide. Sixteen elements as oxides, and LOI (loss on ignition) are determined. The ash samples were prepared in Highbury’s laboratory and sent to BV for analysis. The maximum % the analysis method could accommodate was 10.0 % for V2O5; therefore ash samples were diluted by mixing with other solids. In the Highbury laboratory both Al2O3 and Fe2O3 were used.
Table D. Selected Species in the Ash of Each Coke Type
|Species (wt. %)||Upgrader Coke Ash A||Refinery Coke Ash B|
For Upgrader Coke A, the sum of Al2O3 +SiO2 is about 70 %. V2O5 is about 6.6%, according to the ash analyses. For Refinery Coke B, the average % V2O5 in the ash is 45 %.
Table E Trace Metals Concentration in Ash (mg Metal/kg Ash) for Selected Species [Two Determinations Average]
|Upgrader Coke Ash A||34600||740||130||1840||230||0.02||2.5||1405|
|Refinery Coke Ash B||193000||177000||340||405||620||0.02||0.175||5000|
Vanadium metal concentrations are 3.5 % wt. in Upgrader Coke Ash A, and 19.3 % wt. in Refinery Coke Ash B, which is also enriched in Nickel.
Calculated ash compositions from ICP and XRF methods can show discrepancies due to differences in analytical methods and to the dilution step as used in the present work.
Petcoke is a carbon material by-product of the oil and gas industry that forms during the oil refining process. As refineries have become more efficient at processing extra heavy crude oils (bitumen) over the last two decades, output of Petcoke globally has risen significantly. Because Petcoke originates from heavier petroleum fractions, its denser impurities such as metals and sulphur compounds are concentrated in it.
The majority of Canadian Petcoke output occurs in close proximity to oil sand producing regions, where bitumen is upgraded into synthetic crude oil. Specifically, the Province of Alberta is known to host vast stockpiles of Petcoke. According to the Alberta Energy Regulator, petcoke inventories are estimated to have reached 106 million tonnes in 2016(1).
(1) Source: Alberta Energy Industry, Alberta Mineable Oil Sands Plant Statistics
While concentrations of individual metals are low in raw petcoke, Highbury is utilizing its advanced knowledge of the thermochemical gasification process and existing large-scale pilot plant experience to assist MGX in designing a process to generate hydrogen gas and concentrate metals in the form of ash byproduct. Highbury has completed a Phase I report on potential processes and markets for primary and secondary byproducts. A Phase II study has commenced including analyses of locations, laboratory bench top feedstock results, advanced process design and initial plant design parameters.
