Focus Graphite Unveils Its Highly Conductive Ultrafine and Expanded Graphites For Battery Cathodes Creating a Complete Line of Value-Added Lac Knife Graphite Products for Lithium-Ion and Alkaline Batteries

Focus Graphite Inc. (TSXV:FMS) (OTCQX:FCSMF) (FSE:FKC) is pleased to report that ongoing independent testing of its new ultrafine grades of flake graphite and expanded, natural flake graphite from its Lac Knife, Québec Project demonstrate up to 10 times the electrical conductivity over standard grades of synthetic and natural graphite used in Li-Ion and Alkaline battery cathode applications.

Focus Graphite is the sole owner of the Lac Knife high purity graphite project located just south of Fermont, in the Cote Nord District of Québec. The Company’s aim is to produce value added coated spherical graphite and expanded graphite products for anodes and cathodes used in a range of battery applications.

Focus Graphite’s new superfine grades of flake graphite and the ultrafine grades of expanded graphite were first presented at the 34th International Battery Symposium (IBS) in Fort Lauderdale, Florida, by Dr. Joseph Doninger, Focus’ Director of Technology and Manufacturing on March 21, 2017. (The complete technical presentation entitled Advances in the Performance of Lac Knife Natural Flake and Expanded Graphite in Electrochemical Power Sources” can be accessed by following the link)

Dr. Doninger’s presentation also included the introduction of the Company’s Superfine Coated Spherical Graphite product to add to its standard and fine grades developed previously and an update on long-term battery cycle testing.

The Company’s latest achievements are an extension to Dr. Doninger’s developmental efforts first reported on March 31, 2016 at the 33rd International Battery Seminar. That initial publication of expanded graphite test results demonstrated that the expanded Lac Knife flake graphite produced nearly doubled the electrical conductivity of the cathode mix when compared with the standard competing grades of synthetic and flake graphites.

Expanded graphite is a form of processed natural crystalline flake, featuring dramatically improved electrical conductivity in cathode mixes. Delaminated expanded flake is also preferable to conventional air-milled flake and/or premium quality synthetic graphites when higher conductivity properties are desired.

Figure 1, below, compares the Scanning Electron Photomicrographs (SEMs of purified Lac Knife flake graphite with Focus’ new grade of Lac Knife expanded graphite.

Fig. 1 Comparison of the SEMs of Purified and Expanded Lac Knife Graphite

The SEM of the cross section of the purified flake graphite shows that the graphite is comprised of many layers of finer sized flakes. Focus Graphite used a process to intercalate the flake graphite with acids followed by applying heat to expand the graphite like an “accordion” or “fourth of July worm” which is described in detail in the March 2016 Battery Seminar Presentation. The end result of which is shown in the SEM of expanded graphite where the many layers of the original flake graphite are now separated into extremely thin, almost translucent flakes of graphite which are much more conductive than either standard flake or synthetic graphites.

In electrochemical power sources, such as batteries, the cathode provides the means for the electrons generated in the anode that travel to the powered device to return to the cathode of the cell and complete the circuit. Generally either finely sized synthetic or purified flake graphites are added to the cathode to improve the conductivity of the cathode mixes.

In order to evaluate the effect of adding conductive additives to cathode mixes, it is customary to determine the effect that the conductive additive has on the resistivity of the cathode mix which is described in detail in the March 2016 Battery Seminar Presentation and is shown in Figure 2.

Fig. 2 Comparison of the Resistivities of Lac Knife and Commercial Graphites in Lithium Ion Cathode Mix ( LiNiMnCoO2 )

Figure 2 shows that replacing commercial grades of synthetic and flake graphites with the Lac Knife expanded graphite in the cathode of a Lithium Ion battery greatly reduces the resistivity of the cathode mix in which Lithium Nickel Manganese Cobalt Oxide (LiNiMnCoO2) is the active material thereby greatly increasing the conductivity of the cathode mix.

As shown, if a target of 1 ohm-inches is set for the resistivity of the cathode mix, the amount of expanded graphite that needs to be added to the mix is only 1% as compared with 2.5 to 3.5% for the commercially used standard synthetic and flake graphites. This is important because more of the active material can now be added to the cathode mix thereby providing the opportunity to either increase the capacity or extend the life of the Lithium Ion battery. Conversely, at a concentration of 2 wt % graphite, Focus Graphite’s new ultrafine grade of expanded graphite increases the conductivity of the cathode mix by a factor of 7 to 10 times when compared with standard synthetic and flake graphites.

The same principle can be applied to an alkaline battery where the cathode active material is manganese dioxide and generally not designed to be rechargeable as is shown in Figure 3 below:

Fig. 3 Effect of the Particle Size of Lac Knife Purified Flake Graphite on the Resitivity of Alkaline Cathode Mix ( MnO2 )

Figure 3 compares the resistivity of the two new ultrafine grades of Lac Knife purified flake graphite with the original coarser grades. As shown in the cathode mixes with 3.5% and 4% graphite added to the mix, the resistivity of the cathode mixes made with the two new ultrafine grades are less than half that obtained using the original coarser grades. This, of course, means that the conductivities of the cathode mixes are also more than doubled.

Figure 4 below shows that the ultrafine grades of the Lac Knife purified flake graphite produce cathode mixes with lower resistivities at the 6% graphite addition level and, hence have higher conductivities than were obtained with current commercial grades of flake and synthetic graphites.
Fig. 4 Comparison of the Resistivity of Lac Knife Flake Graphite and Commercial Graphites in Alkaline Cathode Mix (MnO2)

It also should be noted that the excellent conductive properties of both the Lac Knife expanded graphite and ultrafine grades of the flake graphite now provides the battery manufacturer with both the opportunity and flexibility to optimize the performance of the cathode and take full advantage of the output of the anode of both alkaline and lithium ion batteries.

A U.S. based independent battery testing conducted the scientific investigations and testing. The identity of that facility has been withheld for commercially competitive reasons.

The Company intends to continue its long-term cycling testing to 1000 cycles, develop new grades spherical graphite for use in high power applications; develop silicon modified graphite for high capacity applications, and; continue its development of Lac Knife expanded graphite for use in battery cathodes.

Qualified Person

Dr. Joseph Doninger, Focus Graphite’s Director of Technology and Manufacturing is the Qualified Person under National Instrument 43-101 – Standards of Disclosure for Mineral Projects – has reviewed and approved the technical content of this news release. Dr. Doninger is an internationally recognized graphite processing expert and himself, the inventor of a number of patents and an author of over 27 technical papers and presentations related to graphite processing and the use of graphite in energy storage systems. Dr. Doninger is a co-editor on the NATO Science Series book titled “New Carbon Based Materials for Electrochemical Energy Storage Systems”. Dr. Doninger is also an Honorary Professor at the Department of Chemistry from the Kiev National University of Technologies and Design.

About Focus Graphite

Focus Graphite Inc. is an advanced exploration and mining company with an objective of producing graphite concentrate at its wholly owned Lac Knife flake graphite deposit located 27 km south of Fermont, Québec. In a second stage, to meet Quebec stakeholder interests of transformation within the province and to add shareholder value, Focus is evaluating the feasibility of producing value added graphite products including battery-grade spherical graphite.

Focus Graphite is a technology-oriented graphite mining development company with a vision for building long-term, sustainable shareholder value. Focus also holds a significant equity position in graphene applications developer Grafoid Inc.
