Arizona Mining Significantly Expands Taylor Sulfide and Taylor Deeps Zones

Base Metals Investing
Zinc Investing

Arizona Mining Inc. (TSX:AZ) (“Arizona Mining” or the “Company”) announces strong results for two exploration holes from the current drill program focused on expansion of the Taylor Sulfide Zone (“TS”) and Taylor Deeps Zone (“TDS”) located on its 100%-owned Hermosa Project in Santa Cruz County, Arizona.

Arizona Mining Inc. (TSX:AZ) (“Arizona Mining” or the “Company”) announces strong results for two exploration holes from the current drill program focused on expansion of the Taylor Sulfide Zone (“TS”) and Taylor Deeps Zone (“TDS”) located on its 100%-owned Hermosa Project in Santa Cruz County, Arizona. The drill holes highlighted in this release are successful step out exploration drill holes highlighting the continued potential for resource growth and increased grades, as distinct from the Preliminary Economic Assessment (“PEA”) (see Press Release dated April 3, 2017).

“Drill holes HDS-474 and 477 significantly expand the Taylor Sulfide and Taylor Deeps zones and indicate overall higher zinc, lead and silver grades than the average grade of the PEA,” said Chief Operating Officer Don Taylor. “These drill holes north of the Hardshell claim block clearly open up new possibilities for continued expansion of both zones.”

HDS-477 is an angle drill hole (azimuth 330 degrees; -84 degrees inclination) located in the northeast corner of the Hardshell claim block (see Figures 1, 2 and 3).  The drill hole successfully targeted the northern extension of both the Taylor Sulfide and Taylor Deeps mineralization. HDS-477 intersected three significant mineralized horizons in the Taylor Sulfide Zone with a cumulative thickness of 136.5 feet (for individual intervals see Table I).  Notably, drilling also intersected a 366.5-foot thick interval of high grade zinc-lead-silver mineralization in the Taylor Deeps Zone 300 feet further north than any previously reported drilling in this area, and approximately 1,000 feet east of the PEA resource outline.  Most notable of the results from HDS-477 are:

  • 59 feet assaying 5.2% zinc; 3.3% lead; and 4.1 ounces per ton (“opt”) silver (TS)
  • 366.5 feet assaying 7.5% zinc; 7.7% lead; and 5.0 opt silver (TDS)
    • Including 212.5 feet assaying 10.2% zinc; 11.1% lead; and 7.3 opt silver (TDS)

HDS-474 is an angle drill hole (azimuth 053 degrees; -82 degrees inclination) located in the northwest corner of the Hardshell claim block (see Figures 1, 2 and 3).  The hole targeted the Taylor Sulfide and Taylor Deeps zones north of previously reported drilling. HDS-474 intersected an interval of vein-hosted mineralization in the overlying volcanics, a 360-foot interval of continuous mineralization in the Taylor Sulfide Zone, and two significant mineralized horizons in the Taylor Deeps Zone.  Notable assays include:

  • 360 feet assaying 5.0% zinc; 5.0% lead; and 1.7 opt silver (TS)
    • Including 119 feet assaying 10.4% zinc; 10.9% lead; and 3.5 opt silver (TS)
  • 41 feet assaying 7.2% zinc; 15.0% lead; and 6.1 opt silver (TDS)
  • 72 feet assaying 7.7% zinc; 5.1% lead; and 11.9 opt silver (TDS)

For a full list of the Trench Vein, Taylor Sulfide and Taylor Deeps Sulfide mineralized intervals from these holes please refer to Table I.

Table I.  Drill Hole Assay Summary

DH_IDFrom (feet)To (feet)Interval (in feet)From (meters)To (meters)Interval (meters)Ag optPb%Zn% Cu%Zone
HDS-474686691.55.5209.1210.81.76.466.573.360.38TVS
HDS-47423572717360718.4828.1109.71.654.985.010.07TS
Including24472566119745.8782.136.33.5010.8710.380.13TS
HDS-4742931297241893.3905.812.56.0914.977.230.25TDS
HDS-4743103317572945.7967.721.911.945.087.720.94TDS

HDS-4772303236259701.9719.918.04.143.295.170.28TS
HDS-47724022422.520.5732.1738.36.22.242.152.800.13TS
HDS-4772474253157754.0771.417.41.322.032.820.22TS
HDS-4772586.52953366.5788.3900.0111.74.997.707.510.19TDS
Including27372949.5212.5834.2899.064.87.3411.0710.180.26TDS

Drill intersections with a combined zinc and lead grade of greater than 9% are bolded. Sulfide drill intervals from the Taylor Sulfide Zone and Taylor Deeps Sulfide Zone are down-the-hole drill intervals. Vertical drill holes are considered to be within +5% of true width based on the dip of the mineralized stratigraphy at 20-25 degrees. Angle drill holes are considered to be within +15% of true width based on the dip of the mineralized stratigraphy at 20-25 degrees. The exception to this are the intervals noted as veins.  It is not possible to determine the true width of the veins based on the drill density and no representation is made here regarding true width of the veins. Zones shown include; Taylor Sulfide Zone (TS); Taylor Deeps Sulfide Zone (TDS) and Trench Vein System (TVS).

Photos accompanying this announcement are available at
https://www.globenewswire.com/NewsRoom/AttachmentNg/7e9e1ae6-2421-4606-a31d-c635cde0498d
https://www.globenewswire.com/NewsRoom/AttachmentNg/6c4b2e1b-7e12-40a6-aa60-dea5ec0b3662
https://www.globenewswire.com/NewsRoom/AttachmentNg/1f23f1d7-417a-4f89-8e91-622a0f94141e

Qualified Person

The results of the Arizona Mining Inc. drilling have been reviewed, verified and compiled by Donald R. Taylor, MSc., PG, Chief Operating Officer for Arizona Mining Inc., a qualified person as defined by National Instrument 43-101 (NI 43-101). Mr. Taylor has 30 years of mineral exploration and mining experience, and is a Registered Professional Geologist through the SME (registered member #4029597).

Assays and Quality Assurance/Quality Control

To ensure reliable sample results, the Company has a rigorous QA/QC program in place that monitors the chain-of-custody of samples and includes the insertion of blanks, duplicates, and certified reference standards at statistically derived intervals within each batch of samples. Core is photographed and split in half with one-half retained in a secured facility for verification purposes.

Sample preparation (crushing and pulverizing) has been performed at ALS Minerals Laboratories, an ISO/IEC accredited lab located in Tucson, Arizona. ALS Minerals Laboratories prepares a pulp of all samples and sends the pulps to their analytical laboratory in Vancouver, B.C. Canada for analysis. ALS analyzes the pulp sample by ICP following a 4-acid digestion (ME-ICP61 for 33 elements) including Cu (copper), Pb (lead), and Zn (zinc). All samples in which Cu (copper), Pb (lead), or Zn (zinc) are greater than 10,000 ppm are re-run using four acid digestion with an ICP – AES finish (Cu-OG62; Pb-OG62; and Zn-OG62) with the elements reported in percentage (%). Silver values are determined by ICP (ME-ICP61) with all samples with silver values greater than 100 ppm repeated using four acid digestion with an ICP-AES finish (Ag-OG62) calibrated for higher levels of silver contained.  Any values over 1,500 ppm Ag trigger a fire assay with gravimetric finish analysis.  Gold values are determined by a 30 gm fire assay with an ICP-AES finish (Au-ICP21).

About Arizona Mining

Arizona Mining Inc. (an augustagroup company) is a mineral exploration and development company focused on the exploration and development of its 100%-owned Hermosa Project located in Santa Cruz County, Arizona. The Taylor Deposit, a zinc-lead-silver carbonate replacement deposit, has a resource of 8.6 million tons in the Measured Mineral Resource category grading 4.2% zinc, 4.0% lead and 1.6 opt silver, or 9.7% ZnEq, plus 63.8 million tons in the Indicated Mineral Resource category grading 4.5% zinc, 4.4% lead and 1.9 opt silver, or 10.6% ZnEq, and 38.6 million tons of Inferred Mineral Resources grading 4.4% zinc, 4.2% lead and 3.1 opt silver or 11.6% ZnEq, all reported in accordance with NI 43-101 guidelines utilizing a 4% ZnEq cutoff grade. The Taylor Deposit remains open to the north, west and south over land controlled by the Company and will be aggressively drilled to test the limits of the resource. The Company’s other project on the Hermosa property is the Central Deposit, a silver-manganese manto oxide project.
