VANCOUVER, BRITISH COLUMBIA–(Marketwired – March 6, 2017) – Trevali Mining Corporation (TSX:TV) announces the results of its 2017 independent National Instrument 43-101 mineral resource estimate update for the Santander Zinc Mine in west-central Peru.

VANCOUVER, BRITISH COLUMBIA–(Marketwired – March 6, 2017) –Trevali Mining Corporation (TSX:TV) announces the results of its 2017 independent National Instrument 43-101 mineral resource estimate update for the Santander Zinc Mine in west-central Peru. The new estimate defines a measured and indicated resource of 3.8-million tonnes and an inferred resource of 12-million tonnes at a US$40 cut-off (Table 1 and Figure 1 & 2). Mineralization remains open for expansion.
HIGHLIGHTS

  • As part of the Company’s successful rolling-mine plan strategy, exploration has replaced mined inventory and grown the resource over the 2012 to 2016 period with limited investment.
  • Drilling has defined and converted 3.6-million Measured and Indicated tonnes containing approximately 407 million lbs of contained Zn, 69 million lbs of contained Pb and 4.7 million ounces of contained Ag within the Magistral deposits and confirms that the Magistral deposits are now connected at depth (Figures 3 & 4).
  • An approximately 70% conversion rate of Inferred to Measured and Indicated tonnes — thereby providing a high degree of confidence for future drill programs.
  • The new Measured and Indicated tonnes have materially higher metal content when compared to the previous 2012 defined Inferred tonnages with Zn, Pb and Ag grades 29%, 123% and 99% higher respectively on a comparative level-to-level basis.
  • Zinc grades are increasing with depth, which is anticipated to deliver materially more Zn metal units to the processing plant from late-2017 onwards. Anticipated run of mine Zn head grades are anticipated to increase from the current approximately 4-4.5% Zn range to approximately 5-6% Zn in 2018, positioning the Santander mine to capitalize on forecast rising zinc commodity prices during the period and going forward (Figure 4).
  • The discovery of several high-grade mineralized zones on the periphery of the main Magistral bodies: the Fatima, Oyon and Magistral Central-North zones will have an immediate and positive impact on the 2017-2018 mine plans.
  • The Magistral bodies remain open for expansion and the upcoming 2017 resource expansion drill program will in part focus on converting significant inferred tonnages to higher confidence categories in order to grow the resource base and focus on longer range mine planning options including potential operation and metal output expansions.
  • The Company’s committed 2017 exploration program has been tripled to approximately US$3 million, compared to prior years, with additional funds available contingent on success.

“Since commencement of commercial production at Santander in early 2013 our exploration team has consistently delivered excellent results and continues to validate our belief in the significant exploration potential of the Santander mine,” stated Dr. Mark Cruise, Trevali’s President and CEO. “We now have one of the larger, zinc-rich polymetallic systems in the Central Peruvian Mineral Belt and continue to rank the exploration potential as excellent with low-to-moderate risk – essentially everything remains open for expansion. We have identified 17-kilometres of permissive mineral fairway of which only approximately 800-900 metres has been drill tested. Consequently, we feel the likelihood of expanding the current resource and discovering new zones of mineralization going forward remains high.”
DETAILS
The updated resource estimate is based on a refined geologic interpretation of the mineralized zones supported by a significant amount of new data from underground mining and a 2015-2016 drill campaign comprised of an aggregate total of 264 holes totaling 35,487 metres. The results have extended the Measured and Indicated tonnes approximately 150-metres down dip below the previously defined 2012 Indicated resource – effectively replacing mined inventory during the 4-year period (Figure 2 and 3).
The 2017 Santander mine mineral resource estimate was independently estimated by the Company’s consultant Arseneau Consulting Services Ltd (“Arseneau”). The new resource estimate is reported at a US$40 cut-off and calculated to the end of December 2016 mining limits. For reference, Santander’s 2017 operation cost guidance ranges from US$35-to-$40 per tonne.
The total Measured and Indicated resource calculated by Arseneau is 3.8 million tonnes grading 4.85% zinc, 0.85% lead and 1.2 ounces per tonne silver for 406.5 million pounds of contained zinc, 69.3 million pounds of contained lead and 4.7 million ounces of contained silver as tabled below:

GradeContained Metal
DepositClassTonnesZnPbAgCuZn EQ**Zn (MPb (MAg (MCu (M
(M t)(%)(%)(t.oz/t)(%)(%)lbs)lbs)t.oz)lbs)
Combined
(Magistrals,
Fatimas, Oyon,
Santander Pipe)
Measured0.744.100.681.100.074.7466.911.10.81.1
Indicated2.815.280.791.270.086.25327.048.93.65.0
Inferred12.004.220.230.560.094.191,114.860.56.724.8
Magistral Central,
South & Fatima
Measured0.693.950.480.950.074.3160.17.30.71.1
Indicated2.345.580.490.880.085.73287.825.32.14.1
Inferred1.156.270.210.500.085.97158.95.30.61.9
Magistral North &
Oyon
Measured0.056.263.583.260.129.666.94.00.20.1
Indicated0.473.792.313.200.096.5439.323.91.50.9
Inferred0.553.000.832.140.084.2836.310.01.20.9
Santander***Inferred10.104.090.180.470.103.99910.039.04.822.0
Puajanca***Indicated0.252.231.651.250.013.7512.39.10.3
Inferred0.211.991.310.980.013.179.36.10.2

Table 1: 2017 Consolidated Capped Mineral Resource Statement, Santander Mine at US$40 cut-off* after Arseneau.
*Dollar Value Cut-off = ((Ag Price x Ag Recovery x Ag Grade) + (Pb Price x Pb Recovery x (Pb Grade))+(Zn Price x Zn Recovery x (Zn Grade))). Price for silver is ($16.50/oz) and that for Pb ($0.95), Zn ($1.15) and Cu ($2.50) is per pound. A recovery of 74% was applied to Ag, 85% for Pb, 89% for Zn and 0% for Cu for calculating the dollar value formula.
** Zinc equivalent is calculated by dividing the dollar value by the zinc price.
***Resource estimates for Santander Pipe and Puajanca South are unchanged from 2012 but have been updated to reflect 2016 metal prices. Mineral resources were estimated by ordinary kriging inside 5-by-5-by-5 metre blocks for the Magistral deposits and 10-by-10-by-5 metre blocks for the Puajanca and Santander deposits. Assays were capped prior to compositing and assays were composited to 2 metres for the Magistral and Puajanca deposit and 3.5 metres for the Santander deposit.
To view “Figure 1: Location of 2016 Capped Measured, Indicated and Inferred Mineral Resources (red) at Santander Mine; and 2017 Drill Target areas (orange – surface drilling; green – underground drilling),” please visit the following link: https://media3.marketwire.com/docs/1087848_fig1.pdf
To view “Figure 2: 2009 – 2017 Summary of Santander Mine Mineral Resources and Metals – illustrating successful replacement of mined inventory during the period,” please visit the following link: https://media3.marketwire.com/docs/1087848_fig2.pdf
To view “Figure 3: Longitudinal Section (Looking East) of Magistral Deposits, Puajanca and Santander Pipe with 2017 Mineral Resources – illustrating successful replacement of mined inventory during the period,” please visit the following link: https://media3.marketwire.com/docs/1087848_fig3.pdf
The updated Magistral resource estimate is based on 236 drill holes (71,562 metres) and 2,274 channel samples (11,475 metres). The Santander Pipe resource is based on 314 drill holes (19,166 metres) and 973 channels (5,241 metres) and the Puajanca model is based on 12 drill holes (1,953 metres). The resource estimates were prepared by and under the supervision of Dr. Gilles Arseneau, an appropriate “independent qualified person” as this term is defined in National Instrument 43-101. Dassault Systemes Geovia Gems version 6.7 (Gems) software was used to review and modify the geological solids provided by Trevali, prepare assay data for geostatistical analysis, construct the block model, estimate metal grades and tabulate mineral resources. The Geostatistical Software SAGE2001 was used for geostatistical analysis and variography.
A cut-off-grade of US$40 was utilized which is the nominal base-case estimated grade of material that can be mined and processed considering all applicable costs. For reference, the Company’s Santander 2017 site cash cost guidance (mining, milling and site G&A) is US$35-$40 per tonne. The mineral resources identified in Table 1 are based on Ordinary Kriged (OK) capped values inside 5-by-5-by-5-metre blocks for the Magistral deposits and 10-by-10-by-5-metre blocks for the Puajanca and Santander Pipe deposits. Assays were capped prior to compositing and assays were composited to 2 metres for the Magistral and Puajanca deposit and 3.5 metres for the Santander deposit. Resource estimates for Santander Pipe and Puajanca South are unchanged from 2012 but have been updated to reflect 2016 metal prices. The US dollar value cut-off is based on the formula:
Dollar Value = ((Ag Price x Ag Recovery x Ag Grade) + (Pb Price x Pb Recovery x Pb Grade)+(Zn Price x Zn Recovery x (Zn Grade)). Price for silver is ($16.50/oz) and that for Pb ($0.95), Zn ($1.15) and Cu ($2.50) is per pound. A recovery of 74% was applied to Ag, 85% for Pb, 89% for Zn and 0% for Cu for calculating the dollar value formula.
MAGISTRAL DEPOSITS
The 2015-2016 Magistral drill program was largely executed to define and upgrade the Inferred resource to Measured and Indicated categories. During the course of this work, several high-grade zones adjacent to existing and planned underground development were discovered and defined. These zones, Fatima, Oyon and Magistral Central-North, highlight the excellent near-to and in-mine exploration potential that exists and are interpreted to reflect the presence of a large and prolific mineralized Carbonate Replacement Deposit (“CRD”) polymetallic system.
To view “Figure 4: Long-section view, looking west, of the 2017 Magistral Deposits block model classification (Left) and zinc grades of the measured and indicated blocks (Right),” please visit the following link: https://media3.marketwire.com/docs/1087848_fig4.pdf
The 2017 combined inferred tonnage estimate for the Magistral deposits is now 1.7 million tonnes at US$40 cut-off (Table 1 and Figures 2 and 3). Based on widely spaced, deep drill hole intersections and down hole geophysical anomalies that are consistent with the mineral system model, the exploration potential of the Magistral zone is considered excellent and will be a primary focus of the 2017 resource expansion program.
SANTANDER PIPE
The resource estimate for the Santander Pipe has been updated to reflect 2016 commodity prices including new mineral system analysis and represents a very significant potentially mineable Zn inventory (Table 2). The Company believes that very significant exploration potential remains below and adjacent to the Pipe that has never had a focused, sustained, exploration test (Figure 5).

GradeContained Metal
Cut-offTonnes (M t)Zn (%)Pb (%)Ag (t.oz/t)Cu (%)Zn EQ** (%)Zn (M lbs)Pb (M lbs)Ag (M t.oz)Cu (M lbs)
>$1004.136.200.260.580.145.99564.4924.032.4212.31
>$666.925.020.210.530.124.88765.7232.753.6717.53
>$4010.094.090.180.470.103.99909.8638.994.7721.92
>$2512.853.480.140.430.093.40985.3140.815.4624.24
>$018.472.610.100.360.072.571,062.5241.926.5827.69
Total:18.472.610.100.360.072.571,062.5241.926.5827.6

Table 2: Santander Pipe 2017 Capped, Inferred Mineral Resource Statement, at different cut-off* after Arseneau.
*Dollar Value Cut-off = ((Ag Price x Ag Recovery x Ag Grade) + (Pb Price x Pb Recovery x (Pb Grade) + (Zn Price x Zn Recovery x (Zn Grade)). Price for silver is ($16.50/oz) and that for Pb ($0.95), Zn ($1.15) and Cu ($2.50) is per pound. A recovery of 74% was applied to Ag, 85% for Pb, 89% for Zn and 0% for Cu for calculating the dollar value formula.
** Zinc equivalent is calculated by dividing the dollar value by the zinc price.
***Resource estimates for Santander Pipe and Puajanca South are unchanged from 2012 but have been updated to reflect 2016 metal prices. Mineral resources were estimated by ordinary kriging inside 5-by-5- by-5 metre blocks for the Magistral deposits and 10-by-10-by-5 metre blocks for the Puajanca and Santander deposits. Assays were capped prior to compositing and assays were composited to 2 metres for the Magistral and Puajanca deposit and 3.5 metres for the Santander deposit.
To view “Figure 5: Santander Pipe model (left) and a section (right) illustrating location of currently defined Inferred Resources and formerly mined areas. Mineralization remains open for expansion at depth,” please visit the following link: https://media3.marketwire.com/docs/1087848_fig5.pdf
2017 RESOURCE EXPANSION DRILL PROGRAM
An approximately US$3-million 2017 resource definition and exploration drilling campaign of an initial approximately 15,000 metres will be dedicated to the test the down-plunge and lateral (in the hanging wall and footwall) extension and continuity of the Magistral and Pipe deposits. Additionally it is anticipated that a number of high priority drill ready exploration targets (Puajanca, Blato, Blanquita) will also be drill tested.

  • Magistral Deposits – Deep diamond drilling of the contiguous mineralized zone will commence from a dedicated footwall exploration drift positioned at the 4300-metre level of the mine. The proposed drilling is intended to reach the 4,000-metre level, or approximately 300 vertical metres below current development and up to 150 metres below the current inferred resources (Figure 4).
  • Santander Pipe – Extension drilling of the lower portion of the inferred mineral resources is expected to generate new indicated resources that can contribute in the mid-to-long term to the Santander mine throughput profile. Directional drilling coupled with Borehole Electromagnetics (BHEM) is considered for the deeper section of the Pipe. Previous historic drilling, beneath the past workings, has intersected up to 91.5-metres grading 7.8% Zn (Hole 4020J-44W) and 61.7-metres grading 8.1% Zn (Hole 4100L-104E-A).
  • Puajanca, Blato and Blanquita are high priority drill targets located in highly prospective Magistral and Santander trends and coincide with IP chargeability anomalies and favorable structural settings (Figure 1).

A detailed NI43-101 technical report will be filed on SEDAR and the Company’s website within 45-days.
2016 Financial Results and Conference Call
Trevali will release annual financial results for its year ending December 31, 2016 on March 9, 2017 after the close of the trading day in Toronto.
The Company will host a conference call and audio webcast at 10:30 a.m. Eastern Time on Friday, March 10, 2017 to review the financial results. Participants are advised to dial in 5-to-10 minutes prior to the scheduled start time of the call.
Conference call dial-in details:
Toll-free (North America): 1-877-291-4570
Toronto and international: 1-647-788-4919
Audio Webcast: https://www.gowebcasting.com/8400
Qualified Person and Quality Control/Quality Assurance
EurGeol Dr. Mark D. Cruise, Trevali’s President and CEO and Daniel Marinov, P.Geo, Trevali’s VP Exploration, are qualified persons as defined by NI 43-101, have supervised the preparation of the scientific and technical information that forms the basis for this news release. Mr. Marinov is responsible for all aspects of the work, including the quality control/quality assurance programs. Dr. Cruise is not independent of the Company, as he is an officer, director and shareholder. Mr. Marinov is not independent of the Company as he is an officer and shareholder. Drill core samples were processed and assayed in the Santander mine onsite laboratory. Zinc, lead and silver, assays were obtained by Aqua-Regia dissolution followed by Atomic Absorption measurement. Values of lead and zinc over 15% are assayed by volumetric method. Analytical accuracy and precision are monitored by the analysis of reagent blanks, reference material and replicate samples. Quality control is further assured by the use of international and in-house standards. Blind certified reference material is inserted at regular intervals into the sample sequence by Trevali personnel in order to independently assess analytical accuracy. The onsite laboratory is outsourced and managed by SGS-Peru personnel. SGS-Peru’s quality system complies with the requirements for the International Standards ISO 9001:2000 and ISO 17025: 1999. Finally, representative blind duplicate samples are routinely forwarded to an ISO compliant third party laboratory for external quality control.
