Kenorland Minerals Ltd. (TSXV: KLD) (OTCQX: NWRCF) (FSE: 3WQ0) (" Kenorland " or " the Company ") is pleased to report geochemical results from its third phase of sonic 'drill-for-till' geochemical sampling program at the Chicobi Project (the "Project" ), located in the Abitibi greenstone belt of Quebec and held under an earn-in option to joint venture agreement with Sumitomo Metal Mining Canada Limited (SMMCL). The company is further pleased to announce the commencement of detailed geophysical surveys in preparation for diamond drill targeting, tentatively scheduled for Q1 2022.
Kenorland, along with SMMCL, has been exploring the Chicobi Project since 2019 using overburden drilling methods to sample glacial till and top of bedrock below the layer of glaciolacustrine clay that obscures vast areas of the northern Abitibi greenstone belt. To date, three phases of sonic drilling, totaling 441 drill holes have been completed across the Project producing ~1,500 samples for gold grain counts, heavy mineral concentrate assays, and till geochemistry assays. These drill campaigns have systematically screened the property from the regional scale, covering over 50,000 hectares, down to a coherent gold and multi-element till anomaly (Target B) of approximately 1.5km x 3km in extent.
Figure 1. Chicobi Project Lithology and Geochemistry Results
Zach Flood , President and CEO, states, " We're very excited to announce the results from our extraordinary efforts to effectively explore in what we consider the frontier of the the Abitibi. The clay belt presents a unique challenge to exploration which can only be overcome by applying methods such as 'drill-for-till' sampling, which has been effective at detecting mineral systems in other deep glacial cover environments."
Program Highlights
The Company has received all assay and gold grain counts from the Phase 3 sonic drill-for-till geochemical program. A coherent, gold and multi-element (Cu, Zn, Ag, As, Sb) anomaly, 'Target B', was identified from three separate drill-for-till sampling campaigns which began with the property-wide regional survey in the summer of 2019. Detailed geophysical surveys are planned for fall 2021 to refine drill targets within the anomaly. These geophysical surveys include high-resolution drone magnetics, induced polarization (IP), and ground electromagnetics (EM). Initial diamond drill testing is tentatively scheduled for Q1 2022.
Sampling Protocols
Drill-for-till programs were completed using sonic drill rigs in order to penetrate through glaciolacustrine clay into underlying glacial till. Sonic drill cores were retrieved in 1.5m intervals from the drill rig and transported to Kenorland's warehouse in Amos, Quebec . Cores were logged for surficial material and stratigraphy information, then split down the center. One half of the sonic core was stored for archive purposes. The other half of the core was sent for gold grain count analysis (Overburden Drilling Management methodology), heavy mineral concentrate analysis, and fine-fraction till geochemistry analysis.
Figure 2. Chicobi Project Surficial Geology and Geochemistry Results
Gold Grain Counts and Heavy Mineral Concentrate Assays
Overburden Drilling Management (ODM) received and weighed 10 kilogram till samples, and then removed a 300 gram split for archive. Samples were sieved to +/- 2mm: the +2mm fraction was logged for pebble lithology and the -2mm size fraction was sent to a shaker table for heavy mineral concentration. After the shaker table, concentrates were micro-panned for additional concentration of the heavy minerals. At this point, visible gold grains were counted by ODM staff, as well as other metallic minerals.
After gold grain counting, the panned concentrate was then sent to a heavy liquid separation using a liquid with a specific gravity (SG) of 3.3. Heavy minerals which have a density >3.3 g/cm 3 sink to the bottom of the chamber during this process. >3.3 g/cm 3 SG minerals were then subjected to a ferromagnetic separation to remove magnetic minerals such as magnetite and ilmenite. The resulting concentrate was sent to Actlabs for Induced Neutron Activation Analysis (INAA), and a 0.5g split was sent for aqua regia – ICP-MS analysis.
Till Geochemistry Analysis
After the sonic drill core was split, a sample of material was collected down the entire length of the 1.5m half-core until approximately one kilogram of material was extracted. Till geochemistry samples were sent to Bureau Veritas in Timmins, Ontario , where they were dried, then sieved to -63 microns. A 30 gram aliquot of -63 micron material was digested in aqua regia and then analysed by ICP-MS.
About the Chicobi Project
Figure 3. Kenorland Minerals Quebec Project Locations
The Chicobi Project covers 51,257 hectares and over 45 kilometers of strike along the Chicobi Deformation Zone (CDZ), a major, yet under-explored structural break transecting the Abitibi greenstone belt of Ontario and Quebec. Along the strike length of the Project, the CDZ is marked by the juxtaposition of a large sedimentary basin and volcanic packages, and "Timiskaming-type" late-basin polymictic conglomerates. The CDZ is analogous to the other major breaks that host world-class Au deposits of the Abitibi, such as the Cadillac- Larder Lake , Casa-Berardi, and Sunday Lake – Lower Detour deformation zones, and has the potential to host significant orogenic gold and VMS mineralization.
The Chicobi Project is held under an earn-in option to joint venture agreement with Sumitomo Metal Mining Canada Limited (SMMCL) where SMMCL has an option to earn up to 51% interest by funding C$4.9 million in exploration expenditures. SMMCL then has the option to earn an additional 19% by funding an additional C$10 million in exploration expenditures within three years of the initial vesting period. Kenorland would then retain a 30% participating interest. If either party is diluted below 10% their interest would convert to a 2% uncapped NSR.
Qualified Person
Mr. Jan Wozniewski , B. Sc., P. Geo., OGQ (#2239) is the "Qualified Person" under National Instrument 43-101, has reviewed and approved the scientific and technical information in this press release.
About Kenorland Minerals
Kenorland Minerals Ltd. (TSX.V KLD) is a mineral exploration Company incorporated under the laws of the Province of British Columbia and based in Vancouver, British Columbia , Canada. Kenorland's focus is early to advanced stage exploration in North America. The Company currently holds three projects in Quebec where work is being completed under joint venture and earn-in agreement from third parties. The Frotet Project is held under joint venture with Sumitomo Metal Mining Canada Ltd. (SMMCL), the Chicobi Project is optioned to SMMCL, and the Chebistuan Project is optioned to Newmont Corporation. The Company also owns 100% of the advanced stage Tanacross porphyry Cu-Au project as well as an option to earn up to 70% from Newmont Corporation on the Healy Project, both located in Alaska, USA .
Further information can be found on the Company's website www.kenorlandminerals.com
Kenorland Minerals Ltd.
Zach Flood
President and CEO
Tel: +1 604 363 1779
zach@kenorlandminerals.com Kenorland Minerals Ltd.
Francis MacDonald
Executive Vice President
Tel: +1 778 322 8705
francis@kenorlandminerals.com
