Approximately 500 kilograms of sample material was shipped to TOMRA Systems ASA's ("TOMRA") ore-sorting laboratory in Sydney, Australia (see "2022/23 Stockpile Sampling" below). The concentrate produced by sorting was subsequently assayed at Bureau Veritas Australia Pty Ltd.'s laboratory in Sydney. The initial test of the ore-sorting technology comprised a 395-kilogram sample. The test recovered at least 70% of the metals and returned a 41-kilogram concentrate of sorted product of about 10% of the initial mass. Assays for the silver, lead, zinc, copper, and gold in the concentrated product returned the following grades:
Ag (g/t)/(oz/t) | Pb (%) | Zn (%) | Cu (%) | Au (g/t) |
156 / 5.02 | 3.10 | 1.91 | 0.096 | 0.1 |
Compared to average grades documented in the Company's 2014 stockpile evaluation program (see below), ore-sorting increased the silver grade by 6.4 times and the lead and zinc grades by 7 times. Mr. Alston said: "The success of TOMRA's ore-sorting to enhance the grade of the metals of interest in the stockpile is confirmed by the excellent assay results." Mr. Alston emphasized: "Ore-sorting is a proven technology utilized successfully around the world to recover metals from historically mined material. Testing confirmed our expectation that it would work well on our stockpile material."
The Company's 2014 stockpile evaluation program returned an average gold grade of 0.80 g/t for samples collected from 16 locations. The 2014 assay results indicated that the gold grade in the stockpile is variable. CMX believes the low grade for gold assayed in the 2023 ore-sorted product is probably representative of the "nugget effect", which means the sample recovered from the stockpile may or may not have contained more significant gold. Ore-sorting is expected to capture gold in the concentrate when it is present in the stockpile.
2022/23 Stockpile Sampling, Ore-Sorting and Assaying
The Company is working with Sulphide Remediation Inc. ("SRI"), an affiliate of ABH Engineering Inc. of Surrey, B.C. specializing in mineral processing. Under SRI's supervision, approximately 600 kilograms of material was collected from seven separate locations throughout the mine stockpile. The locations duplicated several of the Company's sample sites from its 2014/15 stockpile sampling program (see below). Under the supervision of an SRI representative, samples were transported to Vancouver, B.C., washed and then approximately 500 kilograms of samples were shipped in a secure container to Sydney, Australia. On arrival in Australia, samples were delivered into the custody of TOMRA at its Sydney facility. After completion of ore-sorting tests, the resulting concentrate was delivered by TOMRA to Bureau Veritas' laboratory for assaying.
Bureau Veritas crushed and then pulverized the samples. Metal content was assayed utilizing Inductively Coupled Plasma-Mass Spectrometry (ICP-MS). Samples returning over-limit values (greater than 1%) for lead and zinc were re-submitted for multi-acid digestion followed by Atomic Absorption (AA) analysis. Analysis for gold entailed mixing and then splitting the pulverized samples, followed by fire assay of a 50-gm pulp. No quality assurance/quality control issues were noted with the results reported herein.
Clayton Silver Mine Stockpile
As part of CMX's 2014/15 stockpile evaluation program, over 3,000 kilograms of sample material were collected from 16 locations selected to ensure representative results. Comprehensive analysis of samples confirmed the presence of gold in each sample. Subsequent assays indicated gold to 2.84 g/t with an average of 0.80 g/t for the 16 locations sampled. Statistical averages for the metals of interest from the 16 locations of the mine stockpile sampling program were: gold – 0.80 g/t; silver – 24.31 g/t; lead – 0.44%; zinc – 0.27%.
Historical records suggest most of the stockpile was deposited during mining operations from the 1930's to the 1960's. Processing low-grade ore from the mine during that period was uneconomic due to a combination of milling technology, mining costs and metals prices. As Mr. Alston explained: "Fast forward to today, and modern ore-sorting technology is the key to unlocking the latent value contained in the stockpile. This could provide the Company with the necessary capital to extensively drill the property, which remains largely unexplored, without diluting our shareholders."
About the Clayton Silver Project
The Clayton Silver Property is located in Custer County, south-central Idaho, a mining-friendly state. The 1,131-acre property includes the former Clayton silver-lead-zinc mine on patented claims. The Clayton Mine was developed on eight levels to a depth of 1,100 feet below surface and is comprised of approximately 19,690 feet of underground development. Two major ore bodies were partially mined: the "South Ore Body" and the "North Ore Body".
Recorded production from the Clayton Mine included 7,031,110 oz silver, 86,771,527 lbs lead, 28,172,211 lbs zinc, 1,664,177 lbs copper, and minor amounts of gold from an estimated 2,145,652 tonnes of ore mined between 1934 and 1985 (Hillman, Bob, M.S. Thesis, June 26, 1986, Eastern Washington University).
Very little exploration has been carried out previously on the property. Significant potential is demonstrated in hole 1501-A, drilled in the mid-1960's, which penetrated the mineralized zone at 1,425 feet. At that depth, the hole intercepted 22 feet of mineralization grading 4.07 oz (126 g/t) Ag, 5.75% lead and 5.37% zinc (note: true width is unknown).
Technical and scientific information in this news release was reviewed and approved by Richard Walker, M.Sc. (Geology), P.Geo., recognized as a Qualified Person under the guidelines of National Instrument 43-101. Readers are cautioned that historical information referenced in this news release is not NI 43-101 compliant but has been obtained from sources that the Company believes are reliable.
